    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Ask Lasest Price
    Brand Name : ZHICHENG
    Model Number : ZCF-310
    Price : $16.90/pieces 10-98 pieces
    • Product Details
    • Company Profile

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Good Elasticity Vibration And Noise Reduction Ss304 Flange Connection Flexible Joint Single Sphere Rubber Expansion Bellows

    choose the products of ZHICHENG ?
    1.24 hours online service-- anytime, anywhere can provide what you want.
    2.100% quality inspection before shippment.
    3.Strong production capability and strict quality control.
    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Product Description

    Rubber expansion joints consist of inner and outer rubber, cord layer and steel wire strand, which are vulcanized and then combined with metal flanges or loose sleeves of parallel joints. It is widely used in various pipeline systems.

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    The rubber expansion joints allow for four way movements, and they are molded from synthetic rubber and nylon cord, and this can reduce vibration and noise, and compensate thermal expansion and contraction caused by temperature change.

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Technical parameter

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    NoNameMaterial
    1Outer/inner rubberNR, EPDM, NBR, Neoprene etc.
    2FrameNylon cord fabric
    3Pressurized ringSteel wire strand
    4FlangeCarbon steel galvanized, paint ductile iron, stainless steel etc.
    Operation condition
    Working temperature-15℃~80℃(-30℃~150℃)
    Working pressure6-40bars(PN6-PN40)
    Test pressure1.5 times of working pressure
    Explosion pressure2 times of working pressure
    Applicable mediaAir, water, sewage, sea water, acid, alkali, oil etc.

    Main connection dimension

    Nominal diameter

    Length

    (mm)

    Axial displacement

    Horizontal movement

    (mm)

    Deflection angle

    (a1+a2)°

    Special length

    (mm)

    mm

    inch

    Compression

    (mm)

    Extension

    (mm)

    32

    1 1/4

    95

    9

    6

    9

    15°

    130/150/200

    40

    1 1/2

    95

    10

    6

    9

    15°

    130/150/200

    50

    2

    105

    10

    7

    10

    15°

    130/150/200

    65

    2 1/2

    115

    13

    7

    11

    15°

    130/150/200

    80

    3

    135

    15

    8

    12

    15°

    130/150/200

    100

    4

    150

    19

    10

    13

    15°

    130/200

    125

    5

    165

    19

    12

    13

    15°

    130/150/200

    150

    6

    180

    20

    12

    14

    15°

    130/150/200

    200

    8

    210

    25

    16

    22

    15°

    130/150/200

    250

    10

    230

    25

    16

    22

    15°

    130/150/200

    300

    12

    245

    25

    16

    22

    15°

    130/150/200

    350

    14

    255

    25

    16

    22

    15°

    130/150/200

    400

    16

    255

    25

    16

    22

    15°

    130/150/200

    450

    18

    255

    25

    16

    22

    15°

    200

    500

    20

    255

    25

    16

    22

    15°

    200

    600

    24

    260

    25

    16

    22

    15°

    300

    ( Note: Size range from DN25-3000 are all available, special size and length can also be customized

    please contact us for exact data.

    Production

    ZHICHENG has a strict quality control system, the standard production process, standardized factory testing means to ensure that every product to meet the customer requirements, and provide customers with high-quality products.

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Packaging & Shipping
    Packaging

    1.Inner package: plastic film with carton cases.
    2.Outer package: wooden cases(usually the size of 1100mm*1100mm*1100mm).

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and MoreU PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More


    Product installation

    When the customer installs, we will provide installation instructions, installation notes and maintenance instructions. and this is the installation picture of the DN1800 rubber expansion joint.

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Company Information

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More


    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    U PVC Flange Connection Pvc Pipe Route Special Rubber Expansion Joint for Oil and More

    Pls click here to contact us for more details about the products.

    we will try our best to provide you with quality service and products.

    FAQ

    Q: Are you a trading company or a manufacturer?

    A: We are manufacturers of rubber expansion joints, metal expansion joints, flexible hoses, dismantling joints, trimmer joints, flange adapters and flanges with over 30 years experience.

    Q: Do you have a catalogue?
    A: Yes, we do. Please let me know your email or instant messenger and we will send you our catalogue.

    Q: Can you provide drawings and technical information?
    A: Yes, our specialist technical department will design and supply drawings and technical data.

    Q: Do you provide samples? Are they free of charge or do you charge for them?
    A: Yes, we can provide samples free of charge, but transport costs are borne by the customer.

    Q: Can the products be manufactured to the customer's requirements?
    A: Yes, the above specifications are standard specifications and we can design and manufacture as required.
